Friday, February 3, 2017PrintSubscribe
Custom Logo and Theme

Universal Business Apps (UBA) created with Code On Time are designed to run on desktop and mobile devices.  UBAs may be packaged as native applications and also work in the web browser in online and offline modes. Each app store dictates certain user interface requirements. The new theme framework of Touch UI 2017 makes it easy to fulfill them.

Native applications are distributed through app stores of the operating system verndors. These app stores have a common requirement not to place your logo directly in the user interface, making it visible at all times. The focus must be on application functionality rather than on company branding.

At the same time, it is important to keep the user aware of your brand. Touch UI makes this easy.

Consider the following logo of a fictitious company:


Let’s incorporate this logo into an application created with Code On Time or Cloud On Time.

Creating a Theme Accent

The default theme of the application is Light with Aquarium accent.


We will choose Social accent as a basis for the customization.


Create a copy of the file ~/touch/touch-accent.social.json and name it touch-accent.acme.json. Open the new file in your favorite text editor.


Change the “name” to “Acme”. Find and replace the color #3b5999 with #006940 everywhere in the file. Change header.icon.default from #eee to #ee3a43.  Also change the value of properties button.promo.icon.default and buttons.menu.icon.default to #ee3a43.

Both #006940 and #ee3a43 represent the codes of the main colors used in the log. You can use the standard CSS color names, such as “green” and “red”.

Save the file, switch back to your application, proceed to Themes section under Settings, and select the new theme “Acme”.


The application colors will change to match the branding of our fictitious company. It only took a few minutes to give your app a branded look-and-feel.




image    image

Changing Application Name

The name of the app needs to be changed as well. By default, the name will be derived from the page header text specified in the project settings. If the project’s settings for the header is blank, then the name will read as “Code on Time” or “Cloud On Time”.


There is configuration file in the root of your project, called ~/touch-settings.json. It controls the application behavior and appearance. Open the file and specify appName property to provide a name for the app.


Do not use the brand name there. Instead specify the name that reflects the purpose of the app. Let’s use Inventory Manager for this example. Save the file and refresh the page. The new app name will be visible in the top left corner of the toolbar.


Explicit Branding

The best place to display your branding is the Splash Screen and Account Manager.

The splash screen is displayed briefly when the user starts the app.


The picture on the left side of the screen and the application name can be replaced with alternative images.

Add a new configuration element splash to the file ~/touch-settings.json, as shown in the screenshot below.


Properties logo and background must reference the high-resolution images for the branding of your app. You will need to keep the balance between the quality of the images and their size.

The duration property controls the duration that the splash screen is displayed to users in milliseconds.

Restart the app and see the splash screen displayed.


Your branding is also displayed when the user is automatically logged into the app, or when account manager is activated.


Disabling Themes in Settings

If you do not wish the theme and accent to be changed by the application users, then add settings section to the ~/touch-settings.json with theme option disabled.


Additional settings options can be disabled as needed. The property settings.disabled will prevent the user from modifying any settings.


Further Customization

If your projects requirements call for a prominient display of branding, then you can add a logo to the application toolbar with the help of CSS. Create a file under ~/touch folder with the following rule:


This result of customization is shown next.



Sunday, October 9, 2016PrintSubscribe
Basket Lookup, Wizards, Smart Dates

Release 8.5.11.0 is here! This release contains several major features, bug fixes, as well as major performance enhancements to the Form Rendering Engine in Touch UI.

Basket Lookups

The headliner feature for this release is Basket Lookups. This feature permits using Lookup, AutoComplete, and DropDownList item styles for many-to-many relationships. Property Target Controller is now visible in Project Designer when one of these view styles is selected. The property must point to a compatible data controller that corresponds to the many-to-many junction table in the database.

DropDownList rendered as a basket lookup allows adding multiple territories to an employee using the dropdown control.

Many-to-many relationships permit connecting records together in any combination. Typically, a list of available values are enumerated in a separate table, and a joining table will connect the primary record with a number of values. For example, a product can be tagged with multiple keywords, such as “New”, “Exclusive”, “Discontinued”, and etcetera.

In read-only mode, many-to-many fields are displayed as a comma-separated list of values.

Many-to-many field values are displayed as a comma-separated list in read only mode.

Upon pressing Edit, each item will be rendered in a box, and the input control will be rendered on the following line.

Each item is rendered in a box, with the lookup control on the next line.

The user can tap on an item, or use arrow and Backspace keys to remove items. Typing in or activating the dropdown and selecting an item will add that item to the list. The basket input control behaves just like the original lookup, auto complete, or drop down list control.

Basket Lookups offer a better alternative to the Check Box List (displayed below) when there is a large number of items to choose from.

The Territories many-to-many field rendered as a Check Box List.

Wizards

The Wizard feature is now introduced in Touch UI. The “Wizard” property has been added to categories. When the client library detects that at least one category has the “Wizard” property defined, the form will be rendered in Wizard mode. A list of steps will be enumerated using the values of the “Wizard” property, and a status bar will be shown for the available steps. The “Visible When” property can be used to conditionality hide steps based on field values. Actions “Prev” and “Next” will be automatically injected into “Form” scope, and the “Cancel” action will be moved to the leftmost position.

New Employees form configured as a Wizard in Touch UI.

Click here to learn more about configuring Wizards.

Wizard is the core feature that enables rapid simplified configuration of projects in the upcoming Code On Time V9.

Responsive Templates

The goal of Touch UI is to ensure a consistent and usable UI across a wide range of screen sizes. Automatically created templates will position fields and categories depending on the width of the screen. Release 8.5.11.0 will allow defining multiple view templates based on the screen width.

For example, the Orders form of the Northwind Demo will render in two columns.

The Orders Form in Northwind Demo on larger screens will be rendered in two columns.

On smaller devices, the form will be displayed in one column.

The Orders Form in Northwind Demo on smaller screens will be rendered in one column.

Developers can define multiple templates for different sizes in the HTML view template file by using the “data-layout-size” attribute.  For example, two form layouts can be defined in a file ~/Views/Customers.editForm1.html:

<div data-layout="form" data-layout-size="sm">
    ...
</div>
<div data-layout="form" data-layout-size="tn">
    ...
</div>

When the user opens the form, the client library will parse the file and use the largest possible template that matches the currently available width (minus the sidebar). The possible values are listed below.

Value Minimum Width (px)
tn 0
xxs 480
xs 640
sm 768
md 992
lg 1200
xl 1440

Batch Edit With Dependent Lookups

The previous release overhauled the Batch Edit functionality by rendering a custom form. Each available field is rendered as a checkbox. When the checkbox is enabled, an input is displayed below, and the value of that input will be used to batch update the selected records.

Release 8.5.11.0 now handles the situation with dependent lookups, to ensure that data validity is preserved. When a series of fields are dependent, these fields will be grouped under the same checkbox, and the user is required to set all related values.

Batch Edit with dependent lookups will group the lookups.

Smart Dates

Date values rendered in Touch UI will now display simplified values, such as “Today” or “Next Mon”. These values are much easier for the user to comprehend without having to consult a calendar. Dates between a week ago and in two weeks will show days of the week. Dates occurring this year will show the month and date. Any dates with time values set to 12:00 AM will hide the time. The original value is still viewable by hovering over the text. This feature can be disabled from the user settings.

Orders grid displaying all possible permutations of Smart Dates.

Click here to learn more about Smart Dates.

“Auto” Action Button Location

In previous releases, form action buttons were displayed above and below the form. The default mode for “Show Action Buttons” has been changed to the new value “Auto”. This will render the action buttons in a fixed footer at the bottom of the screen. This ensures that the user always has easy access to the actions available at the time. It also avoids the visual overhead of duplicate button rows on small forms.

The "Auto" Show Action Buttons mode will display a footer containing the form buttons.

Medium size screens will align the buttons to the right of the footer. Larger screens will align the buttons to the center of the footer, to ensure proximity to the inputs. Very small screens, such as those on mobile devices, will display action buttons at the bottom of the form, in order to maximize usable screen space.

Small screens will render buttons at the bottom of the form.

Object References in Touch UI

Object references have made a return in 8.5.11.0! When the form is in read mode, a chevron will be displayed next to the field value. Pressing on the chevron will load the edit form for that record.


To hide the object reference, tag the data field as “lookup-details-hidden”.

Geocode and Calculate Distance

It is now possible to automatically geocode an address value and save the result to predefined Latitude and Longitude fields. Simply tag the relevant address fields with “geocode-city”, “geocode-region”, “geocode-zip”, and “geocode-country”, and tag the positional fields with “geocode-latitude” and “geocode-longitude”. On Insert or Update, if the address values have changed, Google Geocoding API will be queried using the specified API key. The results will be saved in the positional fields.

It is also possible to manually trigger this request inside a C# or Visual Basic business rule, as in the example below.

decimal latitude;
decimal longitude;
if (Geocode(address, out latitude, out longitude))
    Result.ShowAlert("Latitude: " + latitude + ", Longitude: " + longitude);

An additional function has been added to calculate driving distance between two addresses. It can be used in code business rules, as in the example below.

decimal meters = CalculateDistance(sourceAddress, destinationAddress);
decimal miles = meters * 0.00062137m;

Make sure to follow Google Maps APIs Terms of Service when using these functions.

Features and Enhancements

A partial list of new features, enhancements, and fixes in release 8.5.11.0 is shown below.

  • Touch UI
    • Type-sensitive keyboards will be displayed on mobile devices (Number, Phone, URL, Email).
    • “Flicking” horizontally in Grid presentation will scroll one screen at a time.
    • If the HTML file of a view template contains the name of another view template file, that file will be loaded.
    • Forms are now incrementally rendered based on what is visible at the time.
    • Form buttons will align to the right on smaller screens.
    • Auto-complete window will highlight matching text.
    • Field values can now be placed inside category descriptions.
    • If a DateTime field does not allow time selection, selecting the day of the month will hide the input.
    • Tooltip will not cover the Search button in Advanced Search.
    • Resolved issues with Auto Highlight First Row.
    • Resolved issues with Date Picker not setting correct date depending on the order of selection.
    • Mini calendar on sidebar will now resize correctly to display filter values.
    • Removed “Labels In Form” user setting.
    • Actions now support jQuery Mobile icons containing a dash (such as “carat-r”).
    • Removed spinning bar icon in Chrome.
    • Lookups now support Data Text Fields that are numeric types.
    • User theme selection will be differentiated by user name.
  • General
    • Fixed exception with systems that do not have .NET 3.5 installed.
    • Content Framework detection will work with both ASPX controls and HTML pages. This resolves the issue with Bootstrap-based dedicated login pages.
    • Added support for $quickfind and $quickfinddisabled to limit the number of fields included in Quick Find query.
    • Creating a data field in the Project Designer will no longer throw “DataType is undefined” error.
    • Controllers built from data models will use the column configured as the alias as the “Data Text Field”.
    • The “Copy” property will now be configured with the correct name of the field from the lookup controller, instead of the column name.
    • Fixed issue with generated apps using Turkish “i” in the generated code.
    • New JavaScript methods editing() and inserting() can be used in Visible When and Read Only When expressions, as a replacement for this.get_isEditing(). The result is correctly evaluated when user presses “Edit”.
    • Many-to-many fields now show “New Item” if New Data View is enabled, to support adding new items inline.
    • Fixed exception if no models are defined when Project Wizard “Summary” step is opened.
    • Generator will now request to install IIS Express 10.0 if no IIS Express installation is detected.
    • Filter text displayed at the top of views will show a simpler date representation.
    • New implementation of BusinessRules.Whitelist and Blacklist to avoid performance regression.
    • Fields named “Password” or “Pwd” will have Text Mode set to “Password”.
    • Renamed “Click OK” to “Press Save” in resources to account for touchscreen users.
    • Data Objects will no longer create properties for on demand fields.
    • SharePoint Factory option will be hidden if .NET 3.5 is not installed.

In addition to the items listed above, there are a large number of other fixes and performance enhancements.

Thursday, June 9, 2016PrintSubscribe
8.5.8.0 Has Landed! New Form Rendering Engine, Advanced Lookup Input, Calendar Input, Data View Fields, Tiny Density, Save and New

The long awaited release 8.5.8.0 is here! Originally intended to be released in March of 2016, a shift in strategy has resulted in this release coming out in June. We greatly appreciate everyone’s patience, and hope that we find the result to be rewarding for everyone.

Form Rendering Engine

The biggest change in this release is an overhaul of the Form Rendering Engine. One of our biggest complaints for Touch UI was the lack of customizability of the form. The original implementation of forms provided for limited capability in ordering data fields. Categories were used to group data fields into new rows, columns, and tabs.

In response to these comments,we have added the ability to define HTML templates that allow precise positioning of data fields and custom content into the form. A simple example can be seen below.

Example of custom layout template in Touch UI.

These HTML templates will be placed under the ~/Views folder of your project. When loading a view, the application framework will attempt to find the file “[Controller Name].[View ID].html”. If not found, it will generate a default template.

A snippet from the template can be seen below:

<div data-layout="form">
    <div data-container="column" style="width:50%">
        <div data-container="collapsible" data-header-text="Order Information">
            <div data-container="row">
                <div data-control="description">This is the order information.</div>
            </div>
            <div data-container="row">
                <span data-control="label" data-field="CustomerID">CustomerID</span>
                <span data-control="field" data-field="CustomerID">[CustomerID]</span>
            </div>
            <div data-container="row">
                <span data-control="label" data-field="EmployeeID">EmployeeID</span>
                <span data-control="field" data-field="EmployeeID">[EmployeeID]</span>
            </div>...

The entire template must be wrapped in a data-layout element, and various different data-container elements are available for easy positioning of elements. Rows can be used to automatically position fields. It is always possible to use your own elements and position items manually. More documentation on this feature will be coming soon.

These layouts work perfectly well on mobile devices, too.

Example of custom layout template in Touch UI on a small screen.

In order to make the process of developing form templates easy, a visual Form Designer will be included in future releases.

The engine utilizes our new Universal Input API in order to react to user clicks and key presses. When the user clicks on a label or field, the API will find and build the relevant input control in order to handle that field. When the user leaves the field, all values that show that field value will be updated. The API handles Tab, Shift+Tab, Up, Down, Left, Right, Enter, Shift+Enter keys in order to move between fields.

Lookup 2.0

With the new Form Rendering Engine, we decided to overhaul the lookup input control to allow your users to get their work done easier and faster. The new lookup allows the user to type in their search query, and a suggestion list will automatically be loaded. Use arrow keys to navigate up and down in the list. Press Enter on your keyboard to select an option.

The user can click on the arrow to the right of the field to navigate to the lookup view.

New lookup in Form Rendering Engine animation.

The user can also press Ctrl+Space to activate the list. From there, the user can create a new lookup record, or jump to the lookup view by pressing “See All”.  “Ctrl+Enter” will also activate the lookup view.

Client-side data caching and filtering is employed in order to ensure that performance is top-notch.

Calendar Input

Dates have always been a difficult data type to work with. Every browser implements native input differently, some working better than others. Rather than compromising in order to utilize the native input of every browser, a new Calendar Input has been developed. This input control is an extension of the calendar sidebar filter component, which also includes the upgrades.

New Calendar Input in Form Rendering Engine animation.

The input will be activated when the user focuses on the field. Selecting a day in the month will set that date. The user can drag or use the arrow buttons to move between different months. Clicking on the header will allow the user to select the month or year.

If the data field also renders time, a clock will be rendered. The user can click on an area in the clock to set the time. Clicking on the hour or minute part of the header will allow changing that part of the time. Clicking on AM/PM will toggle the time of day.

The user will continue to be able to manually edit the value in the input control.

If the input is activated on a very small screen or mobile device, the Calendar Input will be displayed in the center of the screen. The user must click “OK” to save the new value, “Cancel” to close the popup, or “Clear” to reset the value.

Calendar Input on small screens will cover input and show OK, Cancel, Clear buttons.

Notice that days that contain data in the month are bold. Hovering over the day will reveal a count of records on that day. The client library makes asynchronous requests to pull the data and caches it on the client. If performance is a concern, this feature can be disabled by tagging the data field “calendar-input-data-none”.

Data View Fields

In the past, Code OnTime users needed to configure pages with multiple data views in order to display lists of data related to the master record. This process led to a disconnect between the data and presentation layers of the application.

Release 8.5.8.0 changes the paradigm. A new field type has been introduced, “DataView”. This will allow users to embed lists of records directly into the forms of master records. This change brings controllers more inline with how users would intuitively understand business objects.

Simply define a field of type “DataView”, point to the correct controller, specify the filter field, and create a data field to bind it to the form. All pages that refer to that form will now reveal relevant child records.

Data View field example.

The traditional method of defining child data views still works. This can be used for child data views that should only be displayed on certain pages (or define another view that excludes the data view field).

Future releases of the app generator will allow users to perform inline editing of child records at the same time that the master record is being modified.

Grid Upgrades

This brings us to the new and improved grid. In previous releases, it was difficult to set the size of grid columns to match up with the intended look and feel. Release 8.5.8.0 has made the grid sizing process more transparent.

The grid will now use the exact size of each data field in columns when allocating space. If there are no columns defined, then the columns will be set to 2/3s of the length of the field, or various preconfigured lengths depending on the type of the field.

In order to make the client library more intelligent and require less involvement of the user, a new feature has been added to the grid – “Fit To Width”. This will automatically shrink the grid columns to fit the screen, down to a certain limit. The space allocated to each column is equal to the proportion of “columns” that field was assigned. This feature is automatically enabled for every grid. If the behavior is undesired, the data view can be tagged “grid-fit-none” to disable the functionality.

The width of the grid may surpass the width of the page – the user will then be able to drag the grid left and right to bring different columns into view. Touch input is now supported for dragging.

If a column is too small or big to see the data, the user can click and drag the divider between columns in order to resize.

Animation of grid dragging and column resizing.

Future releases will offer the ability to reorder the columns on the client.

“Tiny” Density

Touch UI applications offer several different display densities in order to fit the needs of every user. The smallest size, Condensed, was still larger than Desktop UI. Therefore, we are introducing “Tiny” display density, which uses the same font and font size of the desktop.

The picture below compares “Comfortable” and “Tiny” display densities.

Orders form with 'Comfortable' display density.    Orders form with 'Tiny' display density.

Business Object Model and Data Access Objects

Code business rules in previous releases of Code OnTime app generator would list each field in the parameters of the method. Controllers with over a hundred fields would result in sprawling and ungainly method signatures. To update a data field for the client, it was necessary to call the UpdateFieldValue() method. See an example of legacy code below.

using System;
using System.Data;
using MyCompany.Data;

namespace MyCompany.Rules
{
    public partial class OrderDetailsBusinessRules : MyCompany.Data.BusinessRules
    {
        [Rule("r100")]
        public void r100Implementation(int? orderID,
            string orderCustomerID,
            string orderCustomerCompanyName,
            string orderEmployeeLastName,
            string orderShipViaCompanyName,
            FieldValue productID,
            string productProductName,
            string productCategoryCategoryName,
            string productSupplierCompanyName,
            FieldValue unitPrice,
            short? quantity,
            float? discount)
        {
            UpdateFieldValue("Quantity", 1);
        }
    }
}

Release 8.5.8.0 will now generate data model objects for each controller that has a code business rule, and will pass this object as a parameter to the method. The setters for each property of the data model object will update the corresponding field on the client side.

using System.Data;
using MyCompany.Data;
using MyCompany.Models;

namespace MyCompany.Rules
{
    public partial class OrderDetailsBusinessRules : MyCompany.Data.BusinessRules
    {
        [Rule("r100")]
        public void r100Implementation(OrderDetailsModel instance)
        {
            instance.Quantity = 1;
        }
    }
}

The new business rule format is vastly easier to read and understand, even for non-professional C# or Visual Basic developers.

Legacy business rules will continue to function as they did before.

Release 8.5.8.0 no longer offers a way to enable data access objects globally. The developer will need to enable data access objects on each controller by enabling the “Generate Data Access Objects” checkbox. These objects will extend the business object models. Models and data access objects will now be stored under ~/App_Code/Models folder.

Miscellaneous

These are just some of the new features in release 8.5.8.0. A more comprehensive list can be seen below:

  • Fields now have the option to be set as “Virtual”. These fields will never be included in Insert or Update queries, but are still editable by the user and can be read and manipulated in business rules. Developers no longer need to mark fields as “not modified” in rules in order to use custom fields.
  • Controllers can now be generated with “Save” and “Save and New” in create forms. By default, new applications will have this enabled by default. It can be toggled with the “Use ‘Save’ and ‘Save and New’ in forms” checkbox in the Features page of the Project Wizard.
  • Vast performance enhancements in page loading, button clicking, form opening, grid rendering and dragging, calendar rendering and dragging. HTTP requests are now smaller and data is cached when possible.
  • Re-selecting a record in the form after creating a record will no longer go back to the grid before loading the edit form. This results in significantly faster workflow when inserting multiple records.
  • Support for Report Viewer 2015.
  • Touch gesture support for Drag & Drop API – tested with Surface Pro 4, iPhone 6 Plus, iPad Pro, Nexus 5x, S7 Edge. This API is used in calendar, grid, calendar input, and panels.
  • Model Builder Tooltip API has been ported to Touch UI.
  • “Borrowed” fields defined in data models will be copied when the lookup value is changed. These fields will now be included as read-only in the create form.
  • Changing namespace of application in Web App Factory will move data model files to correct location.
  • A grey overlay will cover the screen if the user attempts to “double” click an action while another action is executing.
  • Custom scrollbar ensures a uniform user experience across browsers and themes.
  • View templates can exclusively contain the file name of another template. The application framework will load the file with that file name.
  • The text “Loading” will be displayed when the page is loading.
  • Blob Adapters no longer require the user to be logged in when there is no membership enabled.
  • Data Text Field and Data Value Field are initialized correctly if a model exists for the lookup controller.
  • Virtual lookup fields are now correctly created when defined in the data model.
  • Removed installer dependency to .NET 3.5.
  • The web.config file will not be overwritten unless necessary to avoid the “AppDomain Unloaded” message in Visual Studio.
  • Many other minor bug fixes.

We were not able to finalize some of the features that we desired to include in this release, due to time constraints. Expect to see these features in future releases:

  • Modal forms in Touch UI.
  • Grid inline editing (Data Sheet mode).
  • Use of HTML templates to define Grid/List/Card layouts.
  • Swipe left/right action group. Actions placed in this action group will be revealed when user performs the relevant gesture in the grid.
  • Promoted action group. Actions placed in this action group will be revealed when user clicks on the floating promo button at the bottom of the screen.
  • Sidebar will be rendered in the left menu panel when the screen is small or sidebar is disabled.
  • Revealing mini calendar under Calendar mode selector when sidebar is not visible.
  • Reordering of grid columns via drag & drop. The order will be saved in the browser cache.
  • Support for Azure 2.9.
  • “Bucket” lookup will allow selecting multiple items from the lookup view.
  • Rich Text Editor in Touch UI.
  • Visual Form Designer.
  • Multi-day events in Calendar.
